Öhlins Cylinder head 90 pbÖhlins Cylinder head 90 pb
02 · Data & docs

The facts.

Technical data
BrandÖhlins
Part Number05698-01
CategoryCylinder Heads
Country of OriginSweden
DescriptionThe whole story▼

Zylinderkopf 90 Piggyback, Öhlins Artikelnummer 05698-01. Innen liegende Anschläge begrenzen den Kolbenweg und sind Teil des Rohrs.

Wichtigste Merkmale

  • Öhlins Artikelnummer 05698-01
  • Original Öhlins Serviceteil

Was es ist

Öhlins veröffentlicht für diese Position keine Maßangabe; die Nummer ist die Zuordnung. Die Rohrlänge legt den möglichen Hub fest und ist deshalb je Einheit verschieden. Beim Zusammenbau wird der Kopf gleichmäßig angezogen, damit er nicht verkantet. Außen trägt das Rohr oft die Aufnahme für Reservoir oder Ausgleichsbehälter.

Original-Öhlins-Teil

Wer eine Einheit überholt, tauscht selten alles: meist entscheiden wenige Positionen darüber, ob die Dämpfung wieder stimmt. Serviceteile sind das, was ein Fahrwerk vom Verbrauchsartikel unterscheidet. Serienmäßige Positionen halten wir vorrätig; Sonderteile bestellen wir gezielt. Maßgeblich ist die Nummer; Bezeichnungen wiederholen sich bei Öhlins über verschiedene Größen hinweg.

Kanäle im Kopf verbinden Zylinder und Ausgleichsbehälter. Die Oberfläche wird nach dem Honen gespült, damit kein Schleifrückstand ins Öl gerät. Wer die Einheit selbst zerlegt, sollte die Nummern vor dem Ausbau notieren; hinterher sind sie schwer zu lesen. Was nicht am Lager liegt, ordern wir bei Öhlins nach; die Laufzeit nennen wir vor der Bestellung.

Die richtige Nummer finden

Die Nummer 05698-01 ist eindeutig; die Bezeichnung allein ist es nicht, weil Öhlins ähnliche Wortlaute über mehrere Größen verwendet. Korrosion an der Außenseite ist meist kosmetisch; im Inneren ist sie ein Grund zum Tausch. Der Kopf schließt den Zylinder ab und führt die Welle nach außen.

Einbau und Abstimmung

Wir raten dazu, die Einheit von einem autorisierten Öhlins-Service-Center öffnen zu lassen. Wir sind eines und bieten Überholung, Einbau und Abstimmung aus einer Hand an.

Technische Daten

  • Marke: Öhlins
  • Artikelnummer: 05698-01
  • Kategorie: Zylinderköpfe
  • Herkunftsland: Schweden
