The facts.
| Brand | Öhlins |
|---|---|
| Part Number | 06566-02 |
| Category | Adjuster Shafts |
| Dimension A | 296 mm |
| Dimension B | 4.5 mm |
| Country of Origin | Sweden |
DescriptionThe whole story▼
Verstellwelle 296/4.5, Öhlins Artikelnummer 06566-02. Zug- und Druckstufe werden getrennt eingestellt, oft an gegenüberliegenden Enden.
Wichtigste Merkmale
- Öhlins Artikelnummer 06566-02
- Original Öhlins Serviceteil
- Dimension A 296 mm
- Dimension B 4.5 mm
Funktion
Öhlins gibt für diese Position Dimension A 296 mm, Dimension B 4.5 mm an. Der Versteller verändert den Ölquerschnitt und damit die Dämpfung im Betrieb. Verstellwellen laufen in eigenen Dichtungen, die mit dem Alter härten. Sie läuft in einer eigenen Dichtung, die mit dem Alter hart wird.
Original-Öhlins-Teil
Ein Dämpfer ist kein Verschleißteil im Ganzen, sondern eine Baugruppe aus Teilen, die einzeln getauscht werden können. Die Ersatzteilliste folgt der Explosionszeichnung; jede Position hat ihre eigene Nummer, auch wenn zwei Teile gleich aussehen. Die Nummer steht in der Explosionszeichnung der Einheit; danach ist die Bestellung eindeutig. Passt die Nummer nicht zu Ihrer Einheit, melden wir uns vor dem Versand.
Bei größeren Überholungen prüfen wir vorab, welche Positionen zusammengehören. Der Wert eines Öhlins-Fahrwerks liegt in seiner Wartbarkeit — Ersatzteile gibt es für Baureihen, die längst aus dem Programm sind. Zwischen den Rasten liegt ein definierter Winkel; Zwischenstellungen bringen nichts. Die Welle überträgt die Drehbewegung des Verstellers ins Innere. Sie können die Nummer auch mit der Rechnung der letzten Wartung abgleichen.
So passt es sicher
Nummer 06566-02 und Maß gehören zusammen; weicht eines ab, ist es die falsche Position. Ein Versteller mit O-Ring darf nicht über den Anschlag hinaus gedreht werden. Ein Versteller wirkt nur in einem Teil des Geschwindigkeitsbereichs.
Einbau und Abstimmung
Die Arbeit verlangt Spezialwerkzeug und einen sauberen Arbeitsplatz. Wir sind autorisiertes Öhlins-Service-Center und führen Einbau und Abstimmung durch — sprechen Sie uns darauf an.
Technische Daten
- Marke: Öhlins
- Artikelnummer: 06566-02
- Kategorie: Verstellwellen
- Dimension A: 296 mm
- Dimension B: 4.5 mm
- Herkunftsland: Schweden
