Öhlins Top eye 22.2/70The facts.
| Brand | Öhlins |
|---|---|
| Part Number | 10036-04 |
| Category | End Eyes |
| Dimension A | 22.2 mm |
| Dimension B | 70 mm |
| Country of Origin | Sweden |
DescriptionThe whole story▼
Endauge oben 22.2/70, Öhlins Artikelnummer 10036-04. Über das Endauge läuft die gesamte Kraft zwischen Rahmen und Schwinge.
Wichtigste Merkmale
- Dimension A 22.2 mm
- Original Öhlins Serviceteil
- Dimension B 70 mm
- Öhlins Artikelnummer 10036-04
Funktion
Die Serviceliste führt Dimension A 22.2 mm, Dimension B 70 mm. Seine Breite muss zur Aufnahme passen, sonst verspannt sich das Lager. Distanzhülsen im Auge stellen die richtige Einbaubreite her. Gummibuchsen im Auge dämpfen Körperschall und altern mit den Jahren.
Warum das Originalteil
Serviceteile sind das, was ein Fahrwerk vom Verbrauchsartikel unterscheidet. Wer die Einheit selbst zerlegt, sollte die Nummern vor dem Ausbau notieren; hinterher sind sie schwer zu lesen. Kommt die Einheit ohnehin auf die Werkbank, lohnt es sich, die benachbarten Verschleißteile mitzubestellen. Passt die Nummer nicht zu Ihrer Einheit, melden wir uns vor dem Versand.
Maßgeblich ist die Nummer; Bezeichnungen wiederholen sich bei Öhlins über verschiedene Größen hinweg. Die Einheit ist nur so gut wie ihre kleinste Passung; deshalb lohnt sich das Originalteil auch an unscheinbarer Stelle. Bei größeren Überholungen prüfen wir vorab, welche Positionen zusammengehören. Wer die Einheitsnummer des Federbeins kennt, bekommt von uns die passende Teileliste dazu.
Zuordnung über die Nummer
Die Nummer 10036-04 ist eindeutig; die Bezeichnung allein ist es nicht, weil Öhlins ähnliche Wortlaute über mehrere Größen verwendet. Die Breite des Auges muss zur Aufnahme am Rahmen passen. Das Endstück schließt die Einheit ab und nimmt die Befestigung auf.
Einbau und Abstimmung
Eine Dämpferüberholung ist Werkstattarbeit: Die Einheit muss zerlegt, das Shimpaket in der richtigen Reihenfolge wieder aufgebaut und die Gasfüllung neu gesetzt werden. Wir sind autorisiertes Öhlins-Service-Center und übernehmen das komplett — sprechen Sie uns an.
Technische Daten
- Marke: Öhlins
- Artikelnummer: 10036-04
- Kategorie: Endaugen
- Dimension A: 22.2 mm
- Dimension B: 70 mm
- Herkunftsland: Schweden
