The facts.
| Brand | Öhlins |
|---|---|
| Part Number | 03472-60 |
| Category | Cylinder Heads |
| Country of Origin | Sweden |
DescriptionThe whole story▼
Cylinderhead TTX44 168 degrees, 63, Öhlins Artikelnummer 03472-60. Korrosion an der Außenseite ist meist kosmetisch; im Inneren ist sie ein Grund zum Tausch.
Wichtigste Merkmale
- Öhlins Artikelnummer 03472-60
- Original Öhlins Serviceteil
Wo es sitzt
Die Zuordnung läuft über die Nummer, nicht über ein Maß. In ihm sitzen Dichtung und Führung, oft als eine Baugruppe. Beim Zusammenbau wird der Kopf gleichmäßig angezogen, damit er nicht verkantet. Der Innendurchmesser ist auf wenige Hundertstel toleriert, weil der Kolben ohne Ölverlust gleiten muss.
Warum das Originalteil
Öhlins ändert Teile im Laufe einer Baureihe; die Nummer, nicht das Baujahr, sagt, was passt. Serviceteile sind das, was ein Fahrwerk vom Verbrauchsartikel unterscheidet. Wir sind offizieller Öhlins-Vertriebspartner und beziehen die Teile direkt. Wer die Einheitsnummer des Federbeins kennt, bekommt von uns die passende Teileliste dazu.
Nach einem Sturz lohnt die Prüfung auf Verzug, auch wenn das Rohr äußerlich unbeschädigt wirkt. Die Nummer steht in der Explosionszeichnung der Einheit; danach ist die Bestellung eindeutig. Öhlins hält Positionen oft über Modellgenerationen hinweg gleich, tauscht aber ohne Ankündigung Werkstoffe. Bestellt wird über die Artikelnummer. Die Maße darunter sind die, die Öhlins selbst veröffentlicht. Wer sein Fahrwerk regelmäßig warten lässt, kommt mit wenigen Positionen aus; wer wartet, tauscht ganze Baugruppen.
Die richtige Nummer finden
Öhlins führt diese Position in der Explosionszeichnung der zugehörigen Einheit unter 03472-60. Die Bohrung für die Welle ist enger toleriert als die Außenkontur. Das Rohr führt den Kolben und nimmt den Druck auf, den die Dämpfung erzeugt.
Einbau und Abstimmung
Wir raten dazu, die Einheit von einem autorisierten Öhlins-Service-Center öffnen zu lassen. Wir sind eines und bieten Überholung, Einbau und Abstimmung aus einer Hand an.
Technische Daten
- Marke: Öhlins
- Artikelnummer: 03472-60
- Kategorie: Zylinderköpfe
- Herkunftsland: Schweden
