⟲ 360° — drag meThe facts.
| Brand | Öhlins |
|---|---|
| Part Number | FFX 1301 |
| Fitment | KTM 250 XC-W (2017–2023) |
| Road Approval | Not documented by Öhlins |
| Length | 935 mm |
| Stroke | 293 mm |
| Spring Rate | 4,3 N/ |
| Spring Part Number | 02428-43 |
| Recommended Öhlins Oil | 1330 |
| Product Line | RXF 48 S |
DescriptionThe whole story▼
The KTM 250 XC-W in its 2017–2023 form takes Öhlins part number FFX 1301. The front end is where a rider's confidence is won or lost on the 250 XC-W.
Key Features
- Spring part number 02428-43 fitted
- Model-specific fitment for the KTM 250 XC-W (2017–2023) — no modification required
- Delivered with a 4,3 N/mm spring, selected for the 250 XC-W
- 293 mm of travel at the damper
Construction and Material Quality
Tube diameter, offset and axle clamp are all specified per model so the assembly drops into the standard yokes. Öhlins sets a baseline for each part number on the machine it was developed on, so it works before anything is adjusted. Öhlins manufactures in Upplands Väsby, north of Stockholm, and assembles and tests every unit there before it ships.
About the RXF 48 S Range
The S in RXF 48 S stands for the spring conversion: a coil spring replaces the air chamber the standard fork uses. For a rider who wants the fork to feel the same on the last lap as on the first, that is the whole argument. A coil spring holds its rate as the fork heats; an air spring does not, and that is the central argument for the conversion.
Why This Machine Needs It
At 250 cc the 250 XC-W makes enough torque to load the rear hard on corner exit, and the damper has to keep the wheel in contact while that happens. The 2017–2023 generation kept the same chassis dimensions throughout, so one Öhlins number serves the whole run. Enduro use means long days, hot oil and terrain that changes every hundred metres.
Front-End Performance
At 935 mm it matches the standard unit's installed length exactly. Spring part number 02428-43 is a separate catalogue item, so a rate change is inexpensive. The recommended oil is 1330; using something else changes the damping the shim stack was set for. A 4,3 N/mm spring comes fitted, and it is the first thing to reconsider if the rider is heavy or light. Öhlins supplies a baseline setting sheet with the fork. Each function has its own adjuster, which is what allows one change to be judged honestly.
Fitment and Compatibility
Part number FFX 1301 and the KTM 250 XC-W (2017–2023) belong together; other model years take other numbers. The number is shared with 27 sibling models that use the same mounting and settings, and this listing covers the KTM 250 XC-W. Öhlins notes for this application: 08765- spring series *Replaces FFX 0301*
Road Approval
Road approval: not documented by Öhlins for the KTM 250 XC-W. We do not state an approval we cannot evidence — please confirm the current status with us before ordering if you intend to use the motorcycle on public roads.
Fitting and Setup Service
This is not a part to rush. Öhlins recommends installation by an authorised service centre, and we are an authorised Öhlins service centre — fitting, servicing and setup all happen here. Get in touch if you would like the work done with the order.
Specifications
- Brand: Öhlins
- Part Number: FFX 1301
- Fitment: KTM 250 XC-W (2017–2023)
- Road Approval: Not documented by Öhlins
- Length: 935 mm
- Stroke: 293 mm
- Spring Rate: 4,3 N/mm
- Spring Part Number: 02428-43
- Recommended Öhlins Oil: 1330
- Product Line: RXF 48 S
DownloadsOwner's manual · brochure▼
FitmentWhich bikes this fits▼
- KTM 250 XC-W (2017–2023)
