Öhlins PDS Damping cylinder 31/64
02 · Data & docs

The facts.

Technical data
BrandÖhlins
Part Number05643-02
CategoryCylinder Tubes
Diameter31 mm
Length64 mm
Country of OriginSweden
DescriptionThe whole story▼

PDS Damping cylinder 31/64, Öhlins part number 05643-02. Corrosion inside a tube is terminal: it cannot be honed out without changing the clearance.

Key Features

  • Length 64 mm
  • Original Öhlins service part
  • Öhlins part number 05643-02
  • Diameter 31 mm

What It Is

Öhlins publishes 31 mm, 64 mm for 05643-02 — the dimensions are the identity of the part. A scored bore means lost damping, because the oil bypasses the piston rather than being forced through the shims. The cylinder tube is the working bore of the damper: the piston runs in it, and its finish decides how well the piston rings seal. Tubes are replaced when the bore is marked; polishing them out changes the clearance and makes it worse.

Genuine Service Part

The tolerances here are the ones the unit was assembled to, not a pattern equivalent's interpretation of them. Every part in this catalogue is one Öhlins fits itself during assembly and service. If you are unsure which number your unit takes, send us the model and serial number of the damper and we will look it up. We can check the number against the Öhlins exploded view before you order — just ask.

Getting the Number Right

Öhlins identifies this position by the number 05643-02 in the exploded view for the unit it belongs to. diameter 31 mm, length 64 mm is what distinguishes this number from its neighbours in the range. A tube that has been bottomed hard often shows a ring mark; that is a reason to replace it. The cylinder tube is the working bore of the damper: the piston runs in it, and its finish decides how well the piston rings seal.

Fitting and Setup Service

Öhlins recommends that its units are serviced by an authorised centre. We are one: rebuild, revalve and setup all happen in our own workshop.

Specifications

  • Brand: Öhlins
  • Part Number: 05643-02
  • Category: Cylinder Tubes
  • Diameter: 31 mm
  • Length: 64 mm
  • Country of Origin: Sweden
