Öhlins Outer tube 48/116 AL
02 · Data & docs

The facts.

Technical data
BrandÖhlins
Part Number21010-09
CategoryOuter Tubes
Dimension A48 mm
Dimension B116 mm
Country of OriginSweden
DescriptionThe whole story▼

Outer tube 48/116 AL, Öhlins part number 21010-09. Fork legs are matched left and right on most Öhlins forks and are listed separately.

Key Features

  • Original Öhlins service part
  • Dimension B 116 mm
  • Dimension A 48 mm
  • Öhlins part number 21010-09

Function

This one measures 48 mm, 116 mm, and those figures are what separate it from the neighbouring numbers. Fork legs are matched left and right on most Öhlins forks and are listed separately. Outer tubes hold the bushings and the seal head, so their bore finish matters as much as the inner tube's outside. Cartridge tubes sit inside the fork leg and do the actual damping.

Genuine Service Part

A damper that can be rebuilt is a damper that stays on the bike; that is the whole argument for original service parts. Öhlins supports its suspension with individual service parts, which is why a fifteen-year-old damper can still be rebuilt to specification. For a full rebuild, the seal kit plus the wear parts is usually the sensible order. Tell us the damper's model designation and year and we will match the number for you.

How to Be Sure It Fits

21010-09 is the Öhlins number for this position — the same one printed in the service documentation. Öhlins states dimension a 48 mm, dimension b 116 mm for this number, and those figures are the deciding ones. Axle clamps are machined so the axle clamps without pinching the fork out of alignment. Outer tubes are specific to the fork model and its travel.

Fitting and Setup Service

Fitting service parts means opening a pressurised unit. As an authorised Öhlins service centre we do that here, with the right tools and a dyno check afterwards — just ask.

Specifications

  • Brand: Öhlins
  • Part Number: 21010-09
  • Category: Outer Tubes
  • Dimension A: 48 mm
  • Dimension B: 116 mm
  • Country of Origin: Sweden
