Öhlins End eye 16/53/20/26Öhlins End eye 16/53/20/26
02 · Data & docs

The facts.

Technical data
BrandÖhlins
Part Number01054-03
CategoryEnd Eyes
Dimension A16 mm
Dimension B53 mm
Dimension C20 mm
Country of OriginSweden
DescriptionThe whole story▼

End eye 16/53/20/26, Öhlins part number 01054-03. A worn eye bearing is often mistaken for tired damping.

Key Features

  • Dimension A 16 mm
  • Dimension B 53 mm
  • Öhlins part number 01054-03
  • Dimension C 20 mm
  • Original Öhlins service part

What It Is

This one measures 16 mm, 53 mm, 20 mm, and those figures are what separate it from the neighbouring numbers. Thread pitch on end caps is specific to the tube they close. Eye width and bore diameter both have to match the chassis mount. The end eye carries the whole load of the damper into the chassis.

Genuine Service Part

The tolerances here are the ones the unit was assembled to, not a pattern equivalent's interpretation of them. Every part in this catalogue is one Öhlins fits itself during assembly and service. The exploded drawing for your unit names the number; if you do not have it, we do. If you are between two sizes, send us the measurement and we will check it against the catalogue.

How to Be Sure It Fits

The reliable route is the exploded drawing: find the position, read the number, order it — 01054-03 in this case. Öhlins states dimension a 16 mm, dimension b 53 mm, dimension c 20 mm for this number, and those figures are the deciding ones. A worn eye bearing is often mistaken for worn damping. A spherical bearing in the eye lets the damper follow the linkage arc without side load.

Fitting and Setup Service

A damper rebuild is workshop work: it needs the unit dismantled, the shim stack rebuilt in the correct order and the gas charge reset. We are an authorised Öhlins service centre and do exactly that in house — send us the unit or ask us to fit the part with your order.

Specifications

  • Brand: Öhlins
  • Part Number: 01054-03
  • Category: End Eyes
  • Dimension A: 16 mm
  • Dimension B: 53 mm
  • Dimension C: 20 mm
  • Country of Origin: Sweden
