Öhlins End eye 14/50/26Öhlins End eye 14/50/26
02 · Data & docs

The facts.

Technical data
BrandÖhlins
Part Number60220-04
CategoryEnd Eyes
Dimension A14 mm
Dimension B50 mm
Dimension C26 mm
Country of OriginSweden
DescriptionThe whole story▼

End eye 14/50/26, Öhlins part number 60220-04. End caps seal the unit and carry the adjusters; they are matched to the tube they close.

Key Features

  • Dimension A 14 mm
  • Original Öhlins service part
  • Dimension B 50 mm
  • Öhlins part number 60220-04
  • Dimension C 26 mm

Function

This one measures 14 mm, 50 mm, 26 mm, and those figures are what separate it from the neighbouring numbers. Spherical bearings in the eye let the damper move without binding as the linkage arcs. Öhlins machines many eyes from the same billet as the damper body. Eye width and bore diameter both have to match the chassis mount.

Original Öhlins Part

The part number is the contract: it defines material, dimension and finish together. Öhlins supports its suspension with individual service parts, which is why a fifteen-year-old damper can still be rebuilt to specification. Öhlins numbers do not follow a logic you can guess — always read them from the documentation. Öhlins parts are unit-specific: a close dimension is not a substitute.

Getting the Number Right

Öhlins identifies this position by the number 60220-04 in the exploded view for the unit it belongs to. Check dimension a 14 mm, dimension b 50 mm, dimension c 26 mm against what you have removed; a close size is not the same part. A spherical bearing in the eye lets the damper follow the linkage arc without side load. A worn end eye bearing is a common source of rear-end vagueness that gets blamed on damping.

Fitting and Setup Service

Fitting service parts means opening a pressurised unit. As an authorised Öhlins service centre we do that here, with the right tools and a dyno check afterwards — just ask.

Specifications

  • Brand: Öhlins
  • Part Number: 60220-04
  • Category: End Eyes
  • Dimension A: 14 mm
  • Dimension B: 50 mm
  • Dimension C: 26 mm
  • Country of Origin: Sweden
