Öhlins End eyeÖhlins End eye
02 · Data & docs

The facts.

Technical data
BrandÖhlins
Part Number06304-05
CategoryEnd Eyes
Country of OriginSweden
DescriptionThe whole story▼

End eye, Öhlins part number 06304-05. Top eyes with an integrated preload adjuster are listed as one part.

Key Features

  • Original Öhlins service part
  • Öhlins part number 06304-05

Where It Sits

There is no measurement to check here — the number and the exploded view identify it. A worn eye bearing is often mistaken for worn damping. End caps carry adjusters, seals and often the gas valve. A worn end eye bearing is a common source of rear-end vagueness that gets blamed on damping.

Why the Original

Every part in this catalogue is one Öhlins fits itself during assembly and service. The part number is the contract: it defines material, dimension and finish together. Service parts are ordered per piece unless stated otherwise. If you are between two sizes, send us the measurement and we will check it against the catalogue.

Getting the Number Right

06304-05 is the Öhlins number for this position — the same one printed in the service documentation. Öhlins does not publish a dimension here — go by the number and the exploded view. The spherical bearing in an end eye lets the damper follow the linkage without side load. Thread size and eye diameter identify the part.

The eye takes the entire load path from wheel to chassis.

Fitting and Setup Service

Fitting service parts means opening a pressurised unit. As an authorised Öhlins service centre we do that here, with the right tools and a dyno check afterwards — just ask.

Specifications

  • Brand: Öhlins
  • Part Number: 06304-05
  • Category: End Eyes
  • Country of Origin: Sweden
