Öhlins End cap 46/16, clear
02 · Data & docs

The facts.

Technical data
BrandÖhlins
Part Number61065-31
CategoryEnd Caps
Dimension A46 mm
Dimension B16 mm
Country of OriginSweden
DescriptionThe whole story

End cap 46/16, clear, Öhlins part number 61065-31. The end eye carries the entire load of the damper into the chassis, which is why it is machined rather than cast.

Key Features

  • Original Öhlins service part
  • Dimension A 46 mm
  • Öhlins part number 61065-31
  • Dimension B 16 mm

Where It Sits

Dimensionally this is 46 mm, 16 mm, which is how it is told apart from the rest of the range. Thread pitch is specific to the tube — caps are not interchangeable between units. Öhlins machines the eye from the same billet as the body on many units. Thread pitch on end caps is specific to the tube they close.

Why the Original

Öhlins is one of the few suspension makers that still supplies every position in the exploded view as a single part. Öhlins publishes dimensions for its service parts so a workshop can verify before it fits. Order by part number. The dimensions below are the ones Öhlins publishes for it. Tell us the damper's model designation and year and we will match the number for you.

How to Be Sure It Fits

The reliable route is the exploded drawing: find the position, read the number, order it — 61065-31 in this case. Check dimension a 46 mm, dimension b 16 mm against what you have removed; a close size is not the same part. The cap seals against an O-ring, so its face finish matters. Eye width and bore diameter both have to match the chassis mount.

Fitting and Setup Service

Ask us about a full service: as an authorised Öhlins centre we strip, inspect, replace what is worn and set the unit back to its specification.

Specifications

  • Brand: Öhlins
  • Part Number: 61065-31
  • Category: End Caps
  • Dimension A: 46 mm
  • Dimension B: 16 mm
  • Country of Origin: Sweden
