Öhlins Cylinder head 46/26 hose M10
02 · Data & docs

The facts.

Technical data
BrandÖhlins
Part Number01282-17
CategoryCylinder Heads
Diameter46 mm
Length26 mm
ThreadM10
Country of OriginSweden
DescriptionThe whole story▼

Cylinder head 46/26 hose M10, Öhlins part number 01282-17. Diameter and length together identify the tube — both are specific to the damper it came from.

Key Features

  • Thread M10
  • Diameter 46 mm
  • Length 26 mm
  • Öhlins part number 01282-17
  • Original Öhlins service part

Function

01282-17 is the 46 mm, 26 mm version — Öhlins lists each size separately. The tube is what the whole damper is built around: everything else references its bore. The cylinder head closes the working bore and carries the shaft seal and its bushing. Wall thickness and bore finish are what let a cylinder hold pressure without deforming under load.

Why the Original

Öhlins is one of the few suspension makers that still supplies every position in the exploded view as a single part. The part number is the contract: it defines material, dimension and finish together. We can supply the whole position from the drawing rather than the single piece if that is easier. Tell us the damper's model designation and year and we will match the number for you.

How to Be Sure It Fits

Order under 01282-17. Where several sizes share a description, only the number separates them. diameter 46 mm, length 26 mm is what distinguishes this number from its neighbours in the range. Reservoir tubes carry the gas charge and are built to the same standard as the working cylinder. Surface finish is specified in microns, because it decides how quickly the piston band wears.

Fitting and Setup Service

Ask us about a full service: as an authorised Öhlins centre we strip, inspect, replace what is worn and set the unit back to its specification.

Specifications

  • Brand: Öhlins
  • Part Number: 01282-17
  • Category: Cylinder Heads
  • Diameter: 46 mm
  • Length: 26 mm
  • Thread: M10
  • Country of Origin: Sweden
