Öhlins Cylinder head 348ø pb 46/26
02 · Data & docs

The facts.

Technical data
BrandÖhlins
Part Number04871-05
CategoryCylinder Heads
Diameter46 mm
Length26 mm
Country of OriginSweden
DescriptionThe whole story▼

Cylinder head 348ø pb 46/26, Öhlins part number 04871-05. A head that has been over-tightened distorts and stops sealing.

Key Features

  • Öhlins part number 04871-05
  • Length 26 mm
  • Original Öhlins service part
  • Diameter 46 mm

Where It Sits

04871-05 is the 46 mm, 26 mm version — Öhlins lists each size separately. A tube that has been bottomed hard often shows a ring mark; that is a reason to replace it. Wall thickness and bore finish are what let a cylinder hold pressure without deforming under load. The cylinder head closes the working bore and carries the shaft seal and its bushing.

Genuine Service Part

This is an original Öhlins part, not an aftermarket equivalent — the tolerances are the ones the unit was assembled to. Öhlins is one of the few suspension makers that still supplies every position in the exploded view as a single part. Ask us before ordering if you are unsure: a wrong part in a pressurised unit is an expensive lesson. Send us the model and serial number of your unit and we will confirm the position before you order.

How to Be Sure It Fits

Order under 04871-05. Where several sizes share a description, only the number separates them. Check diameter 46 mm, length 26 mm against what you have removed; a close size is not the same part. Tubes are replaced when the bore is marked; polishing them out changes the clearance and makes it worse. Öhlins matches tube and piston as a pair during assembly, which is why the part numbers are specific.

Fitting and Setup Service

We are an authorised Öhlins service centre, so you do not have to source the tools and the nitrogen: send us the damper and we rebuild it with the correct parts and the correct setting.

Specifications

  • Brand: Öhlins
  • Part Number: 04871-05
  • Category: Cylinder Heads
  • Diameter: 46 mm
  • Length: 26 mm
  • Country of Origin: Sweden
