Öhlins Bushing 12/10/8Öhlins Bushing 12/10/8
02 · Data & docs

The facts.

Technical data
BrandÖhlins
Part Number04769-02
CategoryBushings
Inner Diameter12 mm
Outer Diameter10 mm
Length8 mm
Country of OriginSweden
DescriptionThe whole story▼

Bushing 12/10/8, Öhlins part number 04769-02. Both diameters and the length are specification, not approximation.

Key Features

  • Length 8 mm
  • Inner Diameter 12 mm
  • Original Öhlins service part
  • Öhlins part number 04769-02
  • Outer Diameter 10 mm

Where It Sits

Dimensionally this is 12 mm, 10 mm, 8 mm, which is how it is told apart from the rest of the range. Inner and outer diameter both matter; a bushing that is a little loose does more damage than none at all. A bushing is a consumable and is replaced at rebuild rather than reused. Öhlins uses PTFE-coated bushings for a low breakaway force.

Original Öhlins Part

A damper that can be rebuilt is a damper that stays on the bike; that is the whole argument for original service parts. The part number is the contract: it defines material, dimension and finish together. Öhlins numbers do not follow a logic you can guess — always read them from the documentation. Send us the model and serial number of your unit and we will confirm the position before you order.

Identifying the Right Part

Order under 04769-02. Where several sizes share a description, only the number separates them. inner diameter 12 mm, outer diameter 10 mm, length 8 mm is what distinguishes this number from its neighbours in the range. A bushing is a consumable and is replaced at rebuild rather than reused. Guide bushings set the internal alignment of a cartridge.

Fitting and Setup Service

Öhlins recommends that its units are serviced by an authorised centre. We are one: rebuild, revalve and setup all happen in our own workshop.

Specifications

  • Brand: Öhlins
  • Part Number: 04769-02
  • Category: Bushings
  • Inner Diameter: 12 mm
  • Outer Diameter: 10 mm
  • Length: 8 mm
  • Country of Origin: Sweden
