Öhlins Adjustment rod 494.7/3.0
02 · Data & docs

The facts.

Technical data
BrandÖhlins
Part Number15412-09
CategoryAdjustment Rods
Dimension A494.7 mm
Dimension B3.0 mm
Country of OriginSweden
DescriptionThe whole story▼

Adjustment rod 494.7/3.0, Öhlins part number 15412-09. A preload adjuster carries the full spring load and is built as a structural part.

Key Features

  • Original Öhlins service part
  • Öhlins part number 15412-09
  • Dimension B 3.0 mm
  • Dimension A 494.7 mm

Where It Sits

494.7 mm, 3.0 mm: that is the whole specification, and it has to match what came out. Detent balls and springs are separate parts because they wear before the housing does. Öhlins specifies a defined number of clicks per adjuster so a setting is a number, not an impression. Compression and rebound adjusters are not interchangeable even when they look similar.

Why the Original

Rebuilding to specification only works if the parts are to specification — that starts here. Buying the individual part rather than a complete assembly is what makes servicing an Öhlins unit worthwhile. If the unit is already apart, compare the published dimensions with the part in your hand. We can check the number against the Öhlins exploded view before you order — just ask.

Identifying the Right Part

Part number 15412-09 is unambiguous; the description alone is not, because Öhlins uses similar wording across sizes. dimension a 494.7 mm, dimension b 3.0 mm is what distinguishes this number from its neighbours in the range. The adjuster is the part a rider actually touches, and its detents are what make a setting repeatable. Needle and seat together meter the bleed flow; damage to either changes the whole adjustment range.

Fitting and Setup Service

If you would rather not open the damper yourself, we can do it — we are an authorised Öhlins service centre and rebuild these units as a matter of routine.

Specifications

  • Brand: Öhlins
  • Part Number: 15412-09
  • Category: Adjustment Rods
  • Dimension A: 494.7 mm
  • Dimension B: 3.0 mm
  • Country of Origin: Sweden
