K-Tech DDS Pro rear shock absorber for Suzuki GSX-R 1000 2017-2023 360° — drag me
02 · Data & docs

The facts.

Technical data
BrandK-Tech
ModelDDS Pro
Part Number255-017-230-020
FitmentSuzuki GSX-R 1000 (2017–2023)
Length312 mm
Stroke62 mm
Body Diameter35 mm
Shaft Diameter12 mm
Spring Series55–155
Compression Adjustment32 clicks (recommended setting: 12)
DescriptionThe whole story

Engineered for riders who demand precise, consistent suspension performance across every session, the K-Tech DDS Pro shock absorber transforms the chassis dynamics of the Suzuki GSX-R 1000 (2017–2023) into a fully tuneable platform. Whether you are chasing lap times at a club day or running full-bore at a national championship round, the five-way adjustability and Direct Damping System technology mean the rear end works with you, not against you, from the first lap to the last.

Key Features

  • Direct Damping System (DDS) technology minimises cavitation effects for consistent, fade-free damping under sustained high-load conditions
  • Five-way adjustability — compression, rebound, BPV (ByPass Valve) low-speed, hydraulic spring preload, and length — gives precise setup control for any circuit or weather condition
  • 32-click compression adjustment and 32-click rebound adjustment for exceptionally fine-grained damping calibration
  • 16-click BPV setting targets low-shaft-speed damping, improving feel and stability through slower, more complex corners
  • Hydraulic spring preload adjustment makes on-the-spot setup changes clean and repeatable without additional tools
  • Integrated potentiometer mounting points support accurate data-logging and telemetry for data-driven chassis analysis
  • CNC-machined components throughout deliver the dimensional accuracy and structural integrity the race environment demands
  • Race-proven in the British Superbike Championship and at the Isle of Man TT

DDS Technology in Detail

The Direct Damping System separates low-speed and high-speed damping circuits in a way that conventional twin-tube designs cannot match. By routing oil through the bypass valve before it reaches the main compression stack, the DDS Pro controls the shock's response to small, rapid inputs — road texture, chain snatch, minor kerb strikes — without stiffening the overall ride. The result is a rear end that hooks up under acceleration and stays composed over breaking bumps at the end of long straights.

Potentiometer mounting points are machined directly into the body, so a data-acquisition system can monitor real-time shock position throughout a lap. This turns subjective rider feedback into hard numbers, shortening the setup process and making the most of every on-track minute.

Build Quality

Every major structural element is CNC-machined from high-grade aluminium or steel billet. The 35 mm body diameter and 12 mm shaft are sized for the rigours of Superbike-class competition, resisting flex and wear even under repeated hard landings. Spring selection covers the full 55–155 series range, so the unit can be specced precisely to rider weight and riding style from the outset rather than being forced to compensate through damping adjustments.

Fitment and Compatibility

This shock absorber is designed and tested for direct fitment to the Suzuki GSX-R 1000 produced between 2017 and 2023. Part number 255-017-230-020 confirms the correct eye-to-eye length, mount widths, and bolt diameters for this chassis without modification.

Upper mount: eye type, 30 mm width, 10 mm bolt diameter. Lower mount: eye type, 36 mm width, 10 mm bolt diameter. Overall length: 312 mm. Stroke: 62 mm.

Installation requires specialist tools and knowledge. K-Tech recommends fitting by an authorised K-Tech Service Centre to ensure safety and optimal performance.

Specifications

Specification Value
Part Number 255-017-230-020
Fitment Suzuki GSX-R 1000 (2017–2023)
Length 312 mm
Stroke 62 mm
Body diameter 35 mm
Shaft diameter 12 mm
Spring series 55–155
Compression adjustment 32 clicks (recommended: 12)
Rebound adjustment 32 clicks (recommended: 18)
BPV adjustment 16 clicks (recommended: 8)
Spring preload (recommended) 13 mm
Length adjustment range 5 mm
Upper mount Eye, 30 mm wide, 10 mm bolt
Lower mount Eye, 36 mm wide, 10 mm bolt
