Gilles 1DGT riser for BMW R1300GS⟲ 360° — drag me
637 g
02 · Data & docs

The facts.

Technical data
BrandGilles Tooling
Series1DGT
Part number1DGT-04-B
TypeHandlebar risers, pair
MaterialEN AW 7075-T6, upper clamp 6082-T6
Positions36.5 mm up / 27.5 mm back, or 39 mm up / 21 mm back
HandlebarOriginal, 32 mm
Weight637 g (set)
FitmentBMW R1300GS (2023–2026)
Road approvalABE No. KBA 91473 (installation check required)
DescriptionThe whole story▼

The R 1300 GS of 2023 onwards is lighter and more compact than its predecessor, and some riders, especially tall ones, want its bar higher and closer when standing. The 1DGT handlebar risers for the BMW R1300GS move the original 32 mm bar up by as much as 39 mm and closer to the rider.

Key Features

  • Two positions: 36.5 mm up and 27.5 mm back, or 39 mm up and 21 mm back
  • For the original 32 mm handlebar
  • EN AW 7075-T6 body, 6082-T6 upper clamp
  • 637 g for the set
  • Marked GG, 1DGT and KBA 91473
  • ABE No. KBA 91473, installation check required

Two positions

The adjustment table shows two positions: 36.5 mm up and 27.5 mm back, or 39 mm up and 21 mm back. Tall riders and those who ride standing off road often prefer the higher bar.

Material and weight

The risers are machined from EN AW 7075-T6 aluminium with an upper clamp in 6082-T6 and weigh 637 g for the set. They are marked GG, 1DGT and KBA 91473.

Road Approval

ABE No. KBA 91473 lists the R 1300 GS (types GG13 and GG13r) for the 1DGT-04 risers with the original 32 mm handlebar. Unusually for an ABE, it requires an installation check: have the risers inspected by an official testing organisation (TÜV, DEKRA, GTÜ or KÜS) under §19(3) StVZO after fitting, and carry the ABE and the confirmation.

Scope of Delivery

A pair of 1DGT risers with the ABE document, which Gilles includes with the set. The original handlebar is reused.

Specifications

  • Brand: Gilles Tooling
  • Series: 1DGT
  • Part number: 1DGT-04-B
  • Type: Handlebar risers, pair
  • Material: EN AW 7075-T6, upper clamp 6082-T6
  • Positions: 36.5 mm up / 27.5 mm back, or 39 mm up / 21 mm back
  • Handlebar: Original, 32 mm
  • Weight: 637 g (set)
  • Fitment: BMW R1300GS (2023–2026)
  • Road approval: ABE No. KBA 91473 (installation check required)
What's includedEverything in the box▼
  • 2x Gilles 1DGT handlebar riser
  • ABE document No. KBA 91473
DownloadsCertificate▼
ABE certificatePDF

Carry a printed copy of the ABE certificate when riding on German roads.

FitmentWhich bikes this fits▼
  • BMW R1300GS (2023–2026)
