Öhlins Sleeve 10/17/18The facts.
| Brand | Öhlins |
|---|---|
| Part Number | 03204-01 |
| Category | Guides |
| Inner Diameter | 10 mm |
| Outer Diameter | 17 mm |
| Length | 18 mm |
| Country of Origin | Sweden |
DescriptionThe whole story▼
Hülse 10/17/18, Öhlins Artikelnummer 03204-01. Die Länge der Buchse bestimmt, wie gut sie Querkräfte aufnimmt.
Wichtigste Merkmale
- Öhlins Artikelnummer 03204-01
- Innendurchmesser 10 mm
- Original Öhlins Serviceteil
- Länge 18 mm
- Außendurchmesser 17 mm
Funktion
Die Serviceliste führt Innendurchmesser 10 mm, Außendurchmesser 17 mm, Länge 18 mm. Zwischen Buchse und Rohr besteht ein Presssitz, der Spezialwerkzeug verlangt. Ihre Passung zum Rohr ist enger toleriert als ihre Passung zur Welle. Die Buchse führt die Welle und nimmt Querkräfte auf, damit die Dichtung es nicht muss.
Original-Öhlins-Teil
Öhlins ändert Teile im Laufe einer Baureihe; die Nummer, nicht das Baujahr, sagt, was passt. Verschleiß zeigt sich zuerst an den Dichtflächen; Riefen dort bedeuten meist, dass mehr als eine Position fällig ist. Sie können die Nummer auch mit der Rechnung der letzten Wartung abgleichen. Bei mehreren gleich beschriebenen Größen entscheidet allein die Nummer, welche gemeint ist.
Eine Überholung ist günstiger als ein neues Federbein, solange die tragenden Teile in Ordnung sind. Wer eine Einheit überholt, tauscht selten alles: meist entscheiden wenige Positionen darüber, ob die Dämpfung wieder stimmt. Teile aus dem Servicekatalog tragen dieselben Werkstoffe wie die Erstbestückung, nicht nur dieselben Maße. Fotos der ausgebauten Position helfen uns, die Nummer zu bestätigen, bevor Sie bestellen.
Zuordnung über die Nummer
Wer unsicher ist, misst nach — die Angaben unten stammen aus der Öhlins-Serviceliste, 03204-01 ist die zugehörige Nummer. In der Gabel sitzen meist zwei Buchsen pro Holm mit unterschiedlicher Aufgabe.
Einbau und Abstimmung
Als autorisiertes Öhlins-Service-Center bauen wir das Teil auf Wunsch ein und stellen die Einheit anschließend auf Fahrer und Einsatz ein. Eine Anfrage genügt.
Technische Daten
- Marke: Öhlins
- Artikelnummer: 03204-01
- Kategorie: Führungen
- Innendurchmesser: 10 mm
- Außendurchmesser: 17 mm
- Länge: 18 mm
- Herkunftsland: Schweden
