Öhlins End eye 14/110/18/22
02 · Data & docs

The facts.

Technical data
BrandÖhlins
Part Number03154-08
CategoryEnd Eyes
Dimension A14 mm
Dimension B110 mm
Dimension C18 mm
Country of OriginSweden
DescriptionThe whole story▼

Endauge 14/110/18/22, Öhlins Artikelnummer 03154-08. Die Breite des Auges muss zur Aufnahme am Rahmen passen.

Wichtigste Merkmale

  • Dimension A 14 mm
  • Dimension C 18 mm
  • Dimension B 110 mm
  • Öhlins Artikelnummer 03154-08
  • Original Öhlins Serviceteil

Wo es sitzt

Nach Öhlins-Angabe: Dimension A 14 mm, Dimension B 110 mm, Dimension C 18 mm. Seine Breite muss zur Aufnahme passen, sonst verspannt sich das Lager. Anzugsmomente stehen in den Serviceunterlagen und sind nicht beliebig. Die Kappe trägt oft die Kolbenstangenführung mit.

Echtes Serviceteil

Wer sein Fahrwerk regelmäßig warten lässt, kommt mit wenigen Positionen aus; wer wartet, tauscht ganze Baugruppen. Verschleiß zeigt sich zuerst an den Dichtflächen; Riefen dort bedeuten meist, dass mehr als eine Position fällig ist. Die Angaben stammen aus der aktuellen Öhlins-Serviceliste, nicht aus älteren Katalogen. Serienmäßige Positionen halten wir vorrätig; Sonderteile bestellen wir gezielt.

Ihr Gewinde ist auf ein bestimmtes Anzugsmoment ausgelegt. Wir sind offizieller Öhlins-Vertriebspartner und beziehen die Teile direkt. Das Endauge nimmt Zug und Druck auf und wird deshalb geschmiedet, nicht gegossen. Die Ersatzteilliste folgt der Explosionszeichnung; jede Position hat ihre eigene Nummer, auch wenn zwei Teile gleich aussehen. Maßgeblich ist die Nummer; Bezeichnungen wiederholen sich bei Öhlins über verschiedene Größen hinweg.

So passt es sicher

Die Maße stehen unten; sie sind der zweite Prüfpunkt neben der Nummer 03154-08. Ein verzogenes Endstück lässt sich am ungleichmäßigen Verschleiß der Buchse erkennen. Über das Endauge läuft die gesamte Kraft zwischen Rahmen und Schwinge.

Einbau und Abstimmung

Als autorisiertes Öhlins-Service-Center bauen wir das Teil auf Wunsch ein und stellen die Einheit anschließend auf Fahrer und Einsatz ein. Eine Anfrage genügt.

Technische Daten

  • Marke: Öhlins
  • Artikelnummer: 03154-08
  • Kategorie: Endaugen
  • Dimension A: 14 mm
  • Dimension B: 110 mm
  • Dimension C: 18 mm
  • Herkunftsland: Schweden
