Öhlins Shims 8/22/0.30Öhlins Shims 8/22/0.30
02 · Data & docs

The facts.

Technical data
BrandÖhlins
Part Number00188-22
CategoryShims
Inner Diameter8 mm
Outer Diameter22 mm
Thickness0.30 mm
Country of OriginSweden
DescriptionThe whole story▼

Shims 8/22/0.30, Öhlins part number 00188-22. Changing one shim in a stack alters the damping curve measurably; that is why Öhlins sells them individually rather than only as sets.

Key Features

  • Inner Diameter 8 mm
  • Öhlins part number 00188-22
  • Thickness 0.30 mm
  • Outer Diameter 22 mm
  • Original Öhlins service part

Where It Sits

The published figures are 8 mm, 22 mm, 0.30 mm. Measure the old part against them before ordering. Face flatness matters as much as thickness — a shim that does not seal against its neighbour leaks damping. Öhlins grinds shims to a flatness tolerance because the faces have to seal against each other. Öhlins holds thickness to hundredths of a millimetre because that is the resolution damping changes at.

Why the Original

Buying the individual part rather than a complete assembly is what makes servicing an Öhlins unit worthwhile. The part number is the contract: it defines material, dimension and finish together. The exploded drawing for your unit names the number; if you do not have it, we do. Order by part number. The dimensions below are the ones Öhlins publishes for it.

Getting the Number Right

If the unit is already open, compare the dimensions below with the part in your hand before ordering 00188-22. The published dimensions are inner diameter 8 mm, outer diameter 22 mm, thickness 0.30 mm — measure the old part against them if you are unsure. A worn or bent shim shows up as damping that has quietly drifted from the setting sheet. A stack combines several diameters so the curve changes progressively rather than in steps.

Fitting and Setup Service

We are an authorised Öhlins service centre, so you do not have to source the tools and the nitrogen: send us the damper and we rebuild it with the correct parts and the correct setting.

Specifications

  • Brand: Öhlins
  • Part Number: 00188-22
  • Category: Shims
  • Inner Diameter: 8 mm
  • Outer Diameter: 22 mm
  • Thickness: 0.30 mm
  • Country of Origin: Sweden
