Öhlins Spring 1X5X10Öhlins Spring 1X5X10
02 · Data & docs

The facts.

Technical data
BrandÖhlins
Part Number02322-01
CategorySprings
Country of OriginSweden
DescriptionThe whole story▼

Spring 1X5X10, Öhlins part number 02322-01. A spring that has settled in service sits shorter than new and quietly lowers the ride height.

Key Features

  • Original Öhlins service part
  • Öhlins part number 02322-01

Function

There is no measurement to check here — the number and the exploded view identify it. Progressive springs change rate through the stroke and suit short-travel machines. A settled spring lowers the machine without anyone changing a setting. Öhlins publishes sag targets, and those are the reference for choosing a rate.

Original Öhlins Part

The tolerances here are the ones the unit was assembled to, not a pattern equivalent's interpretation of them. Öhlins supports its suspension with individual service parts, which is why a fifteen-year-old damper can still be rebuilt to specification. Order by part number. The dimensions below are the ones Öhlins publishes for it. Öhlins numbers do not follow a logic you can guess — always read them from the documentation.

How to Be Sure It Fits

Order under 02322-01. Where several sizes share a description, only the number separates them. This position has no published dimension, so the part number is the only reliable identifier. A settled spring lowers the machine and steepens the steering without anyone changing a setting. Free length and inner diameter decide whether a spring fits; the rate decides whether it suits.

Fitting and Setup Service

If you would rather not open the damper yourself, we can do it — we are an authorised Öhlins service centre and rebuild these units as a matter of routine.

Specifications

  • Brand: Öhlins
  • Part Number: 02322-01
  • Category: Springs
  • Country of Origin: Sweden
