Öhlins Guide Sleeve MX front fork 48 mm blue
02 · Data & docs

The facts.

Technical data
BrandÖhlins
Part Number02409-04
CategoryFork Parts
Country of OriginSweden
DescriptionThe whole story▼

Guide Sleeve MX front fork 48 mm blue, Öhlins part number 02409-04. Outer tubes hold the bushings and the seal head, so their bore finish matters as much as the inner tube's outside.

Key Features

  • Original Öhlins service part
  • Öhlins part number 02409-04

Function

Öhlins publishes no separate dimension for this position, so the part number carries the identity. Axle clamps are machined so the axle clamps without pinching the fork out of alignment. Inner tubes are coated because they run in bushings and seals for their whole life. Cartridge tubes sit inside the fork leg and do the actual damping.

Genuine Service Part

The tolerances here are the ones the unit was assembled to, not a pattern equivalent's interpretation of them. Öhlins is one of the few suspension makers that still supplies every position in the exploded view as a single part. If you are between two sizes, send us the measurement and we will check it against the catalogue. For a full rebuild, the seal kit plus the wear parts is usually the sensible order.

Getting the Number Right

If the unit is already open, compare the dimensions below with the part in your hand before ordering 02409-04. Where no measurement is given, the drawing position is what identifies the part. Top caps carry the adjusters and the preload mechanism. Cartridge tubes sit inside the fork leg and do the actual damping.

Fitting and Setup Service

If you would rather not open the damper yourself, we can do it — we are an authorised Öhlins service centre and rebuild these units as a matter of routine.

Specifications

  • Brand: Öhlins
  • Part Number: 02409-04
  • Category: Fork Parts
  • Country of Origin: Sweden
