Öhlins Shims 6/12/0.10Öhlins Shims 6/12/0.10
02 · Data & docs

The facts.

Technical data
BrandÖhlins
Part Number01410-12
CategoryShims
Inner Diameter6 mm
Outer Diameter12 mm
Thickness0.10 mm
Country of OriginSweden
DescriptionThe whole story▼

Shims 6/12/0.10, Öhlins part number 01410-12. Outer diameter sets the lever the oil works against, and thickness sets the resistance.

Key Features

  • Outer Diameter 12 mm
  • Inner Diameter 6 mm
  • Original Öhlins service part
  • Thickness 0.10 mm
  • Öhlins part number 01410-12

Function

At 6 mm, 12 mm, 0.10 mm it fits one position only; the next size up carries a different number. Outer diameter sets the lever the oil works against, and thickness sets the resistance. Öhlins holds thickness to hundredths of a millimetre because that is the resolution damping changes at. Two shims of the same thickness but different diameter give completely different curves.

Original Öhlins Part

Öhlins keeps service parts available for units long after they leave the current price list. Öhlins publishes dimensions for its service parts so a workshop can verify before it fits. Send us the model and serial number of your unit and we will confirm the position before you order. If you are between two sizes, send us the measurement and we will check it against the catalogue.

Identifying the Right Part

Öhlins identifies this position by the number 01410-12 in the exploded view for the unit it belongs to. inner diameter 6 mm, outer diameter 12 mm, thickness 0.10 mm is what distinguishes this number from its neighbours in the range. Shim thickness is measured in hundredths of a millimetre because that is the resolution at which damping force changes. Shims are reused only if they are undamaged and flat; a coned shim is finished.

Fitting and Setup Service

A damper rebuild is workshop work: it needs the unit dismantled, the shim stack rebuilt in the correct order and the gas charge reset. We are an authorised Öhlins service centre and do exactly that in house — send us the unit or ask us to fit the part with your order.

Specifications

  • Brand: Öhlins
  • Part Number: 01410-12
  • Category: Shims
  • Inner Diameter: 6 mm
  • Outer Diameter: 12 mm
  • Thickness: 0.10 mm
  • Country of Origin: Sweden
