Öhlins Spring seat 10/64.5/84
02 · Data & docs

The facts.

Technical data
BrandÖhlins
Part Number25600-01
CategorySprings
Dimension A10 mm
Dimension B64.5 mm
Dimension C84 mm
Country of OriginSweden
DescriptionThe whole story▼

Spring seat 10/64.5/84, Öhlins part number 25600-01. Free length and inner diameter decide fit; the rate decides behaviour.

Key Features

  • Öhlins part number 25600-01
  • Dimension A 10 mm
  • Dimension C 84 mm
  • Original Öhlins service part
  • Dimension B 64.5 mm

What It Is

Öhlins publishes 10 mm, 64.5 mm, 84 mm for 25600-01 — the dimensions are the identity of the part. Progressive springs change rate through the stroke and suit short-travel machines. Rate is chosen for rider weight and load, not for the machine alone. Öhlins publishes sag targets, and those are the reference for choosing a rate.

Original Öhlins Part

This is an original Öhlins part, not an aftermarket equivalent — the tolerances are the ones the unit was assembled to. Rebuilding to specification only works if the parts are to specification — that starts here. Order by part number. The dimensions below are the ones Öhlins publishes for it. We can supply the whole position from the drawing rather than the single piece if that is easier.

How to Be Sure It Fits

Öhlins identifies this position by the number 25600-01 in the exploded view for the unit it belongs to. Öhlins states dimension a 10 mm, dimension b 64.5 mm, dimension c 84 mm for this number, and those figures are the deciding ones. Springs are a service part: they age, they settle, and replacing them restores the geometry. Rates are offered in steps so a change can be made in one direction at a time.

Fitting and Setup Service

Fitting service parts means opening a pressurised unit. As an authorised Öhlins service centre we do that here, with the right tools and a dyno check afterwards — just ask.

Specifications

  • Brand: Öhlins
  • Part Number: 25600-01
  • Category: Springs
  • Dimension A: 10 mm
  • Dimension B: 64.5 mm
  • Dimension C: 84 mm
  • Country of Origin: Sweden
