Öhlins Outer tube 52/54/523
02 · Data & docs

The facts.

Technical data
BrandÖhlins
Part Number04760-61
CategoryOuter Tubes
Dimension A52 mm
Dimension B54 mm
Dimension C523 mm
Country of OriginSweden
DescriptionThe whole story▼

Outer tube 52/54/523, Öhlins part number 04760-61. A marked inner tube destroys seals repeatedly until it is replaced.

Key Features

  • Original Öhlins service part
  • Dimension A 52 mm
  • Öhlins part number 04760-61
  • Dimension C 523 mm
  • Dimension B 54 mm

Where It Sits

04760-61 is the 52 mm, 54 mm, 523 mm version — Öhlins lists each size separately. Öhlins publishes tube diameters by fork model, and they are not interchangeable across the range. Axle clamps and lower legs are machined to hold the axle without distorting the fork. Top caps carry the adjusters and the preload mechanism.

Original Öhlins Part

Öhlins numbers every position so a workshop can order precisely what it needs, not a whole assembly. Öhlins keeps service parts available for units long after they leave the current price list. We can check the number against the Öhlins exploded view before you order — just ask. Tell us the damper's model designation and year and we will match the number for you.

Getting the Number Right

The reliable route is the exploded drawing: find the position, read the number, order it — 04760-61 in this case. The published dimensions are dimension a 52 mm, dimension b 54 mm, dimension c 523 mm — measure the old part against them if you are unsure. Öhlins publishes tube diameters by fork model, and they are not interchangeable across the range. Fork tubes are the structural part of the front end and carry the braking load into the yokes.

Fitting and Setup Service

Ask us about a full service: as an authorised Öhlins centre we strip, inspect, replace what is worn and set the unit back to its specification.

Specifications

  • Brand: Öhlins
  • Part Number: 04760-61
  • Category: Outer Tubes
  • Dimension A: 52 mm
  • Dimension B: 54 mm
  • Dimension C: 523 mm
  • Country of Origin: Sweden
