Öhlins Shaft rod TPX 16/11/220
02 · Data & docs

The facts.

Technical data
BrandÖhlins
Part Number05510-04
CategoryDamper Shafts
Diameter16 mm
Length11 mm
Country of OriginSweden
DescriptionThe whole story▼

Shaft rod TPX 16/11/220, Öhlins part number 05510-04. A shaft is threaded at both ends: one for the piston, one for the mounting.

Key Features

  • Diameter 16 mm
  • Öhlins part number 05510-04
  • Length 11 mm
  • Original Öhlins service part

Function

Öhlins publishes 16 mm, 11 mm for 05510-04 — the dimensions are the identity of the part. Shaft diameter sets the displaced volume, which is why it is part of the damper's specification. Surface hardness is what lets the shaft survive thousands of cycles through a seal. This is a part that is replaced rather than repaired.

Original Öhlins Part

Öhlins supports its suspension with individual service parts, which is why a fifteen-year-old damper can still be rebuilt to specification. The part is identical to what Öhlins fits in production — same supplier, same specification. Öhlins numbers do not follow a logic you can guess — always read them from the documentation. Service parts are ordered per piece unless stated otherwise.

Identifying the Right Part

The reliable route is the exploded drawing: find the position, read the number, order it — 05510-04 in this case. The published dimensions are diameter 16 mm, length 11 mm — measure the old part against them if you are unsure. Corrosion on a stored damper usually starts on the exposed shaft. Shaft diameter sets the volume displaced into the reservoir on every compression stroke.

Fitting and Setup Service

We are an authorised Öhlins service centre, so you do not have to source the tools and the nitrogen: send us the damper and we rebuild it with the correct parts and the correct setting.

Specifications

  • Brand: Öhlins
  • Part Number: 05510-04
  • Category: Damper Shafts
  • Diameter: 16 mm
  • Length: 11 mm
  • Country of Origin: Sweden
