Öhlins Cylinder head 36/26 M10 Black
02 · Data & docs

The facts.

Technical data
BrandÖhlins
Part Number00201-19
CategoryCylinder Heads
Diameter36 mm
Length26 mm
ThreadM10
FinishBlack
Country of OriginSweden
DescriptionThe whole story▼

Cylinder head 36/26 M10 Black, Öhlins part number 00201-19. Diameter and length together identify the tube — both are specific to the damper it came from.

Key Features

  • Diameter 36 mm
  • Thread M10
  • Öhlins part number 00201-19
  • Original Öhlins service part
  • Finish: black
  • Length 26 mm

Where It Sits

At 36 mm, 26 mm it fits one position only; the next size up carries a different number. The cylinder is one of the few damper parts that is genuinely wear-limited. Öhlins hones its tubes to a defined surface finish rather than simply to a diameter. A scored bore means lost damping, because the oil bypasses the piston rather than being forced through the shims.

Genuine Service Part

Öhlins is one of the few suspension makers that still supplies every position in the exploded view as a single part. Öhlins numbers every position so a workshop can order precisely what it needs, not a whole assembly. Send us the model and serial number of your unit and we will confirm the position before you order. Service parts are ordered per piece unless stated otherwise.

Identifying the Right Part

00201-19 is the Öhlins number for this position — the same one printed in the service documentation. The published dimensions are diameter 36 mm, length 26 mm — measure the old part against them if you are unsure. A head that has been over-tightened distorts and stops sealing. A scored bore means lost damping, because the oil bypasses the piston rather than being forced through the shims.

Fitting and Setup Service

A damper rebuild is workshop work: it needs the unit dismantled, the shim stack rebuilt in the correct order and the gas charge reset. We are an authorised Öhlins service centre and do exactly that in house — send us the unit or ask us to fit the part with your order.

Specifications

  • Brand: Öhlins
  • Part Number: 00201-19
  • Category: Cylinder Heads
  • Diameter: 36 mm
  • Length: 26 mm
  • Thread: M10
  • Finish: Black
  • Country of Origin: Sweden
