Öhlins End piece clevis 56/20/10 With thread locker
02 · Data & docs

The facts.

Technical data
BrandÖhlins
Part Number15085-09
CategoryEnd Caps
Dimension A56 mm
Dimension B20 mm
Dimension C10 mm
Country of OriginSweden
DescriptionThe whole story▼

End piece clevis 56/20/10 With thread locker, Öhlins part number 15085-09. Thread pitch on end caps is specific to the tube they close.

Key Features

  • Original Öhlins service part
  • Öhlins part number 15085-09
  • Dimension A 56 mm
  • Dimension B 20 mm
  • Dimension C 10 mm

What It Is

Dimensionally this is 56 mm, 20 mm, 10 mm, which is how it is told apart from the rest of the range. The spherical bearing in an end eye lets the damper follow the linkage without side load. Spherical bearings in the eye let the damper move without binding as the linkage arcs. Öhlins machines the eye from the same billet as the body on many units.

Why the Original

The part is identical to what Öhlins fits in production — same supplier, same specification. The alternative to a service part is usually a new damper, which is why this catalogue exists. We can check the number against the Öhlins exploded view before you order — just ask. Order by part number. The dimensions below are the ones Öhlins publishes for it.

Getting the Number Right

Part number 15085-09 is unambiguous; the description alone is not, because Öhlins uses similar wording across sizes. dimension a 56 mm, dimension b 20 mm, dimension c 10 mm is what distinguishes this number from its neighbours in the range. Öhlins anodises caps for corrosion resistance where they are exposed. A worn end eye bearing is a common source of rear-end vagueness that gets blamed on damping.

Fitting and Setup Service

Öhlins recommends that its units are serviced by an authorised centre. We are one: rebuild, revalve and setup all happen in our own workshop.

Specifications

  • Brand: Öhlins
  • Part Number: 15085-09
  • Category: End Caps
  • Dimension A: 56 mm
  • Dimension B: 20 mm
  • Dimension C: 10 mm
  • Country of Origin: Sweden
