Öhlins Ball joint 14/28/17The facts.
| Brand | Öhlins |
|---|---|
| Part Number | 05536-52 |
| Category | Ball Joint Spacers |
| Dimension A | 14 mm |
| Dimension B | 28 mm |
| Dimension C | 17 mm |
| Country of Origin | Sweden |
DescriptionThe whole story▼
Ball joint 14/28/17, Öhlins part number 05536-52. Circlips hold axial position under load; a sprung one lets the assembly walk.
Key Features
- Öhlins part number 05536-52
- Original Öhlins service part
- Dimension C 17 mm
- Dimension A 14 mm
- Dimension B 28 mm
Where It Sits
The published figures are 14 mm, 28 mm, 17 mm. Measure the old part against them before ordering. Öhlins lists these individually because a service usually needs a handful of them. Retaining rings come in a groove-specific thickness — the next size does not hold. Pins and dowels locate parts to each other; without them the assembly is merely clamped, not positioned.
Why the Original
Öhlins supports units that are decades old, which is why the spare parts list runs to thousands of numbers. Öhlins supports its suspension with individual service parts, which is why a fifteen-year-old damper can still be rebuilt to specification. Öhlins parts are unit-specific: a close dimension is not a substitute. Send us the model and serial number of your unit and we will confirm the position before you order.
Getting the Number Right
The reliable route is the exploded drawing: find the position, read the number, order it — 05536-52 in this case. Öhlins states dimension a 14 mm, dimension b 28 mm, dimension c 17 mm for this number, and those figures are the deciding ones. Stainless where corrosion matters, hardened where load matters — the choice is made per position. Circlips hold axial position under load; a sprung one lets the assembly walk.
Fitting and Setup Service
Öhlins recommends that its units are serviced by an authorised centre. We are one: rebuild, revalve and setup all happen in our own workshop.
Specifications
- Brand: Öhlins
- Part Number: 05536-52
- Category: Ball Joint Spacers
- Dimension A: 14 mm
- Dimension B: 28 mm
- Dimension C: 17 mm
- Country of Origin: Sweden
