Öhlins Adjuster shaft 98.5/4.3
02 · Data & docs

The facts.

Technical data
BrandÖhlins
Part Number00566-19
CategoryAdjuster Shafts
Dimension A98.5 mm
Dimension B4.3 mm
Country of OriginSweden
DescriptionThe whole story▼

Adjuster shaft 98.5/4.3, Öhlins part number 00566-19. Detent balls and springs are separate parts because they wear before the housing does.

Key Features

  • Öhlins part number 00566-19
  • Dimension A 98.5 mm
  • Dimension B 4.3 mm
  • Original Öhlins service part

Where It Sits

98.5 mm, 4.3 mm: that is the whole specification, and it has to match what came out. Preload adjusters carry the full spring force and are built accordingly. Detent balls and springs are separate parts because they wear before the housing does. Öhlins builds click adjusters with defined detents so a setting can be written down and returned to.

Original Öhlins Part

Buying the individual part rather than a complete assembly is what makes servicing an Öhlins unit worthwhile. Öhlins numbers every position so a workshop can order precisely what it needs, not a whole assembly. If you are unsure which number your unit takes, send us the model and serial number of the damper and we will look it up. Öhlins parts are unit-specific: a close dimension is not a substitute.

Getting the Number Right

The reliable route is the exploded drawing: find the position, read the number, order it — 00566-19 in this case. Öhlins states dimension a 98.5 mm, dimension b 4.3 mm for this number, and those figures are the deciding ones. Adjuster housings carry seals, and a leak there empties the damper as surely as a shaft seal. A bent adjuster shaft binds and the clicks become uneven.

Fitting and Setup Service

Fitting service parts means opening a pressurised unit. As an authorised Öhlins service centre we do that here, with the right tools and a dyno check afterwards — just ask.

Specifications

  • Brand: Öhlins
  • Part Number: 00566-19
  • Category: Adjuster Shafts
  • Dimension A: 98.5 mm
  • Dimension B: 4.3 mm
  • Country of Origin: Sweden
