Öhlins Adjuster shaft 232.8/4.3
02 · Data & docs

The facts.

Technical data
BrandÖhlins
Part Number03566-74
CategoryAdjuster Shafts
Dimension A232.8 mm
Dimension B4.3 mm
Country of OriginSweden
DescriptionThe whole story▼

Adjuster shaft 232.8/4.3, Öhlins part number 03566-74. The adjuster shaft runs inside the damper shaft and carries the adjustment to the piston.

Key Features

  • Öhlins part number 03566-74
  • Dimension A 232.8 mm
  • Original Öhlins service part
  • Dimension B 4.3 mm

Where It Sits

Öhlins publishes 232.8 mm, 4.3 mm for 03566-74 — the dimensions are the identity of the part. Needle and seat together meter the bleed flow; damage to either changes the whole adjustment range. Electronically controlled adjusters replace the needle with a solenoid but keep the same hydraulics. A worn adjuster loses its clicks, and with them any chance of a methodical setup.

Original Öhlins Part

This is an original Öhlins part, not an aftermarket equivalent — the tolerances are the ones the unit was assembled to. The alternative to a service part is usually a new damper, which is why this catalogue exists. Send us the model and serial number of your unit and we will confirm the position before you order. The Öhlins exploded view names the number for each position; we can look it up if you do not have it.

Identifying the Right Part

The reliable route is the exploded drawing: find the position, read the number, order it — 03566-74 in this case. Check dimension a 232.8 mm, dimension b 4.3 mm against what you have removed; a close size is not the same part. The adjuster shaft runs inside the damper shaft and carries the adjustment to the piston. Öhlins publishes the click count for each unit, and a rebuilt adjuster should return it.

Fitting and Setup Service

Fitting service parts means opening a pressurised unit. As an authorised Öhlins service centre we do that here, with the right tools and a dyno check afterwards — just ask.

Specifications

  • Brand: Öhlins
  • Part Number: 03566-74
  • Category: Adjuster Shafts
  • Dimension A: 232.8 mm
  • Dimension B: 4.3 mm
  • Country of Origin: Sweden
