Öhlins Cyl. tube 36/170 ext.thread Al
02 · Data & docs

The facts.

Technical data
BrandÖhlins
Part Number04320-17
CategoryService Parts
Dimension A36 mm
Dimension B170 mm
Country of OriginSweden
DescriptionThe whole story▼

Cyl. tube 36/170 ext.thread Al, Öhlins part number 04320-17. An original Öhlins service part, listed under its own number in the Öhlins spare parts catalogue.

Key Features

  • Original Öhlins service part
  • Dimension A 36 mm
  • Öhlins part number 04320-17
  • Dimension B 170 mm

Function

04320-17 is the 36 mm, 170 mm version — Öhlins lists each size separately. The number on the part matches the number in the drawing, which makes identification unambiguous. Replacement parts come from the same production as the components they go into. Availability of individual parts is one reason Öhlins units stay in service for decades.

Why the Original

Öhlins supports units that are decades old, which is why the spare parts list runs to thousands of numbers. A damper that can be rebuilt is a damper that stays on the bike; that is the whole argument for original service parts. If you are between two sizes, send us the measurement and we will check it against the catalogue. The exploded drawing for your unit names the number; if you do not have it, we do.

Identifying the Right Part

Order under 04320-17. Where several sizes share a description, only the number separates them. The published dimensions are dimension a 36 mm, dimension b 170 mm — measure the old part against them if you are unsure. Öhlins does not sell service parts as pattern equivalents — there is one specification. Service parts are what make an Öhlins unit worth rebuilding rather than replacing.

Fitting and Setup Service

Ask us about a full service: as an authorised Öhlins centre we strip, inspect, replace what is worn and set the unit back to its specification.

Specifications

  • Brand: Öhlins
  • Part Number: 04320-17
  • Category: Service Parts
  • Dimension A: 36 mm
  • Dimension B: 170 mm
  • Country of Origin: Sweden
