Öhlins End eye 16/53/20/26 Groove
02 · Data & docs

The facts.

Technical data
BrandÖhlins
Part Number01054-49
CategoryEnd Eyes
Dimension A16 mm
Dimension B53 mm
Dimension C20 mm
Country of OriginSweden
DescriptionThe whole story▼

End eye 16/53/20/26 Groove, Öhlins part number 01054-49. A worn end eye bearing is a common source of rear-end vagueness that gets blamed on damping.

Key Features

  • Original Öhlins service part
  • Dimension B 53 mm
  • Dimension A 16 mm
  • Dimension C 20 mm
  • Öhlins part number 01054-49

What It Is

Öhlins gives it as 16 mm, 53 mm, 20 mm; nothing about that is approximate. Öhlins machines many eyes from the same billet as the damper body. Spherical bearings in the eye let the damper move without binding as the linkage arcs. Thread size and eye diameter identify the part.

Genuine Service Part

The alternative to a service part is usually a new damper, which is why this catalogue exists. A damper that can be rebuilt is a damper that stays on the bike; that is the whole argument for original service parts. Order by part number. The dimensions below are the ones Öhlins publishes for it. Tell us the damper's model designation and year and we will match the number for you.

Getting the Number Right

Part number 01054-49 is unambiguous; the description alone is not, because Öhlins uses similar wording across sizes. dimension a 16 mm, dimension b 53 mm, dimension c 20 mm is what distinguishes this number from its neighbours in the range. End caps seal the unit and carry the adjusters; they are matched to the tube they close. End caps carry adjusters, seals and often the gas valve.

Fitting and Setup Service

Fitting service parts means opening a pressurised unit. As an authorised Öhlins service centre we do that here, with the right tools and a dyno check afterwards — just ask.

Specifications

  • Brand: Öhlins
  • Part Number: 01054-49
  • Category: End Eyes
  • Dimension A: 16 mm
  • Dimension B: 53 mm
  • Dimension C: 20 mm
  • Country of Origin: Sweden
